Details:
- Material Aircraft Aluminum
- Motor Brushless motor
- System Direct drive System
- Stroke 2.5-5.0mm Internal adjustable stroke
- 5 Options（2.5,3.5,4.0,4.5,5.0）
How to Adiust the Bearing:
- Loosen the bearing screw using a 1.3mm hex screwdriver.
- Adjust the bearing scale with a 1.3mm flat-head screwdriver.
- After achieving the desired setting, tighten the screw securely.
Timing Function
- It will begin timing when the UniK is opened, and retain the timing data even after the battery is changed.
- Timing reset by holding both the "+" and "-" buttons for 3s
Memory function
- H mode:Press m button to switch to M1 or M2 memory gear.
- L mode:Press m button to switch to Mi or M2 memory gear.
- (The yellow font shows the current working mode and memory gear.）
Normal Mode Voltage adjustment
Two adjustment methods：
- Press "+" or "-" button, increase or decrease the voltage by 0.1V
- Hold "+" or "-" button, increase or decrease the voltage by 1V
Torque mode:
Double click M button, switch to Torque mode
Different power at the same frequency. The power of high torque will be stronger.
- High Torque mode:High-torque motor ensures consistent penetration forcrisp line work
- Low Torque mode:Lower torque output provides smoother needle actionfor gradient shading
Product Details:
Screen: 1.47inch ， OLED HD Color screen
Battery: 18500 Lithium-ion， 1600mAh
Battery Voltage: 3.7V
Power Intake: 5w
Needle Protrusion: 0-5mm
Charging Input: 5V/2A
Pen Net Weight: 218g
Pen Size: 127mm* 32mm
Grip Diameter: 39mm and 32mm
Color: Black
Content:
1 machine, 1 extra battery, 1 extra grip, 1 charging head, 1 data cable, 1 flat-head screwdriver, 1 hexagonal wrench, 1 travel bag, 1 outer box, 1 instruction Manual
Features:
- The internal stroke is adjustable from 2.5 to 5.0mm, a unique feature. It can be set to 2.5mm, 3.5mm, 4.0mm, 4.5mm, or 5.0mm.
- Equipped with two built-in 18500 battery packs for longer working hours.
- Adopts a direct-drive system with low wear and more direct power transmission.
- The OLED HD color screen displays Bluetooth connection status, battery level, working voltage, frequency, and working time
- Memory function with four positions, H: M1,M2 ＆L: M1,M2
- Two modes:
- High torque mode(H)：motor ensures consistent penetration for crisp line work
- Low torque mode(L): output provides smoother needle action for gradient shading
- Equipped with an extra grip: adapted to the preferences of different tattoo artists
- Bluetooth function：Can be connected to AVA Bluetooth foot pedal for Bluetooth control
- OLED high-definition screen displays the machine's working status, allowing for better observation and control of the machine
- It adopts a brushless motor, providing stronger power, longer service life and higher accuracy.
- Internal adjustable stroke, 1pc UNIK meets many needs during the tattoo process
